BIAX機器人系統和擺動驅動器產品有：
BIAX機器人系統與撓度
BIAX撓度與快速變化系統的機器人系統
BIAX撓度與 HSK 工具擬合機器人系統。CENTORK定位器
BIAX擺動驅動器

BIAX機器人系統和擺動驅動器產品描述：
BIAX機器人系統與撓度
撓曲力是通過壓縮空氣調整連續可調
壓縮空氣應用于活塞可確保該工具總是返回到起始位置在固定站后的撓度。BIAX撓性驅動器
BIAX機器人系統與撓度產品：

Type designation	RWA 2-40	RWA 2-30	RWA 2–22	RWA 5-12	RWA 2-24
Integrated grinding spindle	R 3040	R 3030	R 3622	R 4112	TR 3624
	Oil-lubricated	Oil-lubricated	Oil-lubricated	Oil-lubricated	Dry-run
Order number	150 830 835	150 830 820	150 830 825	150 830 885	150 830 860
Speed (min -1)	40,000	30,000	22,000	12,000	24,000
Power (Watt)	240	240	300	400	300
Tool mounting hole max.	8	8	8	10	8
Collet type (mm)	ZG 7/6	ZG 7/6	ZG 7/6	ZG 8/6	ZG 7/6
Direction of rotation	clockwise	clockwise	clockwise	clockwise	clockwise
Exhaust air direction	forward	forward	forward	forward	forward
Weight (g)	1120	1135	1400	2095	1465
Air inlet	R 1/8"	R 1/8"	R 1/8"	R 1/4"	R 1/8"
Overall length X (mm)	193	193	207	263	219
Grinding spindle length dimension S (mm)	110	110	124	176	138
Tool mounting hole length W (mm)	83	83	83	87	81
Chop spindle length Z (mm)	41	41	41	31	51
Spindle dia. D (mm)	30	30	36	41	36

BIAX撓度與快速變化系統的機器人系統

ASV 100
這個系統使并行撓度的紡錘波，簡化編程。工具自動復位到零位置。
BWS 2 22 & BWSO 2-22
這些機器人系統允許機器人單元格中的工具快速交換。額外紡錘體不同革命是可用的。

BIAX撓度與快速變化系統的機器人系統產品：

Type designation	ASV 100	BWS 2-22	BWSO 2-22
Integrated grinding spindle	R 3622	R 3622	R 3622
	Oil-lubricated	Oil-lubricated	Oil-lubricated
Order number	150 832 000	150 830 940	150 831 030
Speed (min -1)	22,000	22,000	22,000
Power (Watt)	300	300	300
Tool mounting hole max.	8	8	8
Collet type (mm)	ZG 7/6	ZG 7/6	ZG 7/6
Direction of rotation	clockwise	clockwise	clockwise
Exhaust air direction	forward	rear	rear
Weight (g)	2420	2400	2350
Air inlet	2 x R 1/8"	robot sided	robot sided
Systems with more spindles and different numbers of revolutions available on request. Additional technical information by request.

撓度與 HSK 工具擬合機器人系統

RWA HSK 系統
這些工具是雙向拉伸 RWA 線的變種。HSK 100 或 HSK 63 工具配件使用RWA 主軸在機床。工具是可用的有或沒有個別調整的接觸壓力調節閥。BFI緊湊型火焰控制器

BIAX撓度與 HSK 工具擬合機器人系統產品：

Type designation	RWA 2-40 - HSK	RWA 2-30 - HSK	RWA 2–22 - HSK	RWA 5-12 - HSK	RWA 2-24 - HSK
Integrated grinding spindle	R 3040	R 3030	R 3622	R 4112	TR 3624
	Oil-lubricated	Oil-lubricated	Oil-lubricated	Oil-lubricated	Dry run
Order no. with regulating valve HSK 100	150 831 091	150 831 081	150 831 061	150 831 101	150 831 071
Order no. without regulating valve HSK100	150 831 090	150 831 080	150 831 060	150 831 100	150 831 070
Order no. with regulating valve HSK 63	on demand	on demand	150 831 063	on demand	on demand
Order no. without regulating valve HSK 63	-	-	-	-	-
Speed (min -1)	40,000	30,000	22,000	12,000	24,000
Power (Watt)	240	240	300	400	300
Tool mounting hole max.	8	8	8	10	8
Collet type (mm)	ZG 7/6	ZG 7/6	ZG 7/6	ZG 8/6	ZG 7/6
Direction of rotation	clockwise	clockwise	clockwise	clockwise	clockwise
Exhaust air direction	forward	forward	forward	forward	forward
Weight (g)	4480	4480	4700	6500	4700
Air inlet	R 1/8"	R 1/8"	R 1/8"	R 1/4"	R 1/8"
Additional technical information for RWA 5-12-HSK available by request.

BIAX擺動驅動器

擺動驅動器非常適合于在繪圖儀來切割紙板、 聚苯乙烯和其他材料的使用。此外，此工具可以去毛刺部分，當工件引導到機器人。
也可以是 FR 8 2 歸檔工具。這是一個直線的氣動工具，在機器人的版本中。德國BFI
BIAX擺動驅動器產品：

Type designation	F 5-4 R	F 5-4 R SA	F 5-4 R SA	PLV 01	AG 90
Order no.	150 310 820	150 310 825	150 310 830	150 310 910	150 310 900
Stroke rate (min)	4,000	4,000	4,000	12,000	12,000
Stroke length (mm)	1-5	3	2	8-9	2-9
Drive type	Vane motor with swash plate drive			Reciprocating piston
Tool mounting hole max. (mm)	3	3	3	6	up to 6
Exhaust air direction	rear	rear	rear	rear	rear
Weight (g)	960	960	960	1200	1900
Matching hose unit	001 366 505	001 366 505	001 366 505	001 974 552	001 974 552
Additional technical information for PLV 01 available by request.

瑞士BIAX工具替代了傳統的刮研方式，效率更高，更準確，更** ，用于鑄鋼，硬質鑄鐵，可鍛鑄鐵以及其他金屬、非金屬材料的加工等 。BIAX工具包括：BIAX電動剪、BIAX電動銼、BIAX電動鋸、BIAX電動磨光機、BIAX電動刮刀。
